2 ton Small Excavator 2T-1
High-Power, Fuel-Efficient Engine：Equipped with the Laidong385 engine delivering 19 kW, ensuring strong performance, reduced fuel consumption, and smooth, low-vibration operation.
Optimized Hydraulic System：The perfectly matched hydraulic system offers easy, precise control, with fixed-position hoses designed to avoid interference and damage during operation.
Flexible Configuration Options：Provides optional features such as a rocker arm, retractable tracks, and a closed cabin to meet different working conditions and user needs.
Wide Compatibility with Attachments：Supports multiple attachments—including quick hitch, narrow bucket, hammer, auger, tilt bucket, ripper, rake, grapple, tree shears, and mower—enhancing versatility for various tasks.
2 Ton Mini Excavator Overview
LAIDONG HIGH-EFFICIENCY ENGINE
The Hightop 2-ton mini excavator is equipped with the Laidong385 engine, delivering up to 19 kW of power for strong performance and fuel efficiency, along with even heat distribution. It operates smoothly with minimal vibration, ensuring reliable, long-lasting use.
OPTIMIZED HYDRAULIC SYSTEM
The 2,000 kg mini excavator offers easy and precise maneuverability. The hydraulic hose is securely fixed to prevent contact during operation. Optional configurations include a rocker arm, retractable tracks, and an enclosed cabin.
COMPATIBLE WITH MULTIPLE ATTACHMENTS
This 2-ton excavator can be fitted with a wide range of tools, such as a hydraulic quick hitch, narrow bucket, hammer, auger, tilt bucket, ripper, rake, rotary grapple, tree shears, and lawn mower—allowing one machine to handle a variety of tasks.
INVERTED BOOM CYLINDER
The inverted boom cylinder design significantly increases digging depth.
PROTECTED OIL HOSE DESIGN
The concealed oil hose layout enhances machine protection and prolongs hose service life.
ADDED RETURN LINE
A new additional oil return line for the travel motor improves performance and reliability.
2ton Small Excavator Parameter
| Model: | 2.0T-1 |
| Engine: | Laidong 385 3TN25 |
| Main Valve: | Beifang |
| Total length/transportation length: | 3337/2597mm |
| Total width: | 1100mm |
| Upper width: | 1053mm |
| Total height (cab roof): | 2325mm |
| Standard track plate width: | 180mm |
| Track Gauge: | 920mm |
| Minimum ground clearance: | 119mm |
| Tail turning radius: | 1013mm |
| Track ground length: | 1050mm |
| Track length: | 1545mm |
| Weight: | 2000kg |
| Bucket capacity: | 0.02m³ |
| Rated power: | 19KW/2200RPM |
| Slewing speed : | 12RMP |
| Climbing capacity: | 30° |
| Maximum digging height: | 2580mm |
| Maximum unloading height: | 1637mm |
| Maximum digging depth: | 2060mm |
| Maximum digging distance: | 3130mm |
| Minimum Slewing Radius: | 1575mm |
| Maximum height at minimum turning radius : | 2075mm |
